Protect internal parts with this genuine OEM waveguide cover, part number 5304523276, for select Frigidaire Microwaves.

Waveguide Cover


arqspin

JVM1860SF001

JVM1870SF001

JVM1870SF02

LVM1335BW02

LVM1420BA01

LVM1420WA01

RVM1335BC001

RVM1335WC001

RVM1435BD001

RVM1435BD002

Microwave not heating

This is a Genuine Replacement Part. General Electric (GENF0) WB27X10017 Microwave Magnetron.

The magnetron uses high voltage, high current DC power to generate the microwave frequency that cooks the food. If the magnetron burns out, the microwave won’t heat. The magnetron is not repairable—if the magnetron is burned out, you must replace it. (Warning: The microwave oven can store a lethal amount of electricity in its high voltage capacitor, even after the microwave oven has been unplugged. Due to the high running voltage and the potential for electric shock, it is extremely dangerous to replace the electronic components in a microwave. Only a licensed technician should replace the magnetron.)

Microwave is sparking or arcing

If the microwave is sparking or arcing behind the waveguide cover in the oven cavity, you will likely see smoke or there will be a burning smell. The appliance's magnetron is one of the components that could be damaged and causing the sparking or arcing. Inspect the magnetron for burn marks or damage and replace if necessary.

Microwave is loud or noisy

The magnetron uses high voltage, high current DC power to generate the microwave frequency that cooks the food. Under normal circumstances, the magnetron emits a low hum. However, if the magnetron is damaged or nearly burned out, it may begin emitting high-pitched sounds or growling noises. If the magnetron is noisy, this indicates that the magnetron is nearing the end of its life or might be defective. A defective high-voltage diode can also cause the magnetron to be loud. Before replacing the magnetron, first test the high voltage diode. If the diode is not defective, replace the magnetron. (Warning: The microwave oven can store a lethal amount of electricity in its high voltage capacitor, even after the microwave oven has been unplugged. Due to the high running voltage and the potential for electric shock, it is extremely dangerous to replace the electronic components in a microwave. Only a licensed technician should replace the magnetron.)

Microwave is tripping circuit breaker

A microwave that is tripping a circuit breaker can be caused by a shorted magnetron. You can determine that a magnetron has shorted by contacting one multimeter lead to one of the magnetron's terminals and the other lead to the casing. If meter display indicates that electrical continuity is present between any of the terminals and the casing, the magnetron has shorted and will need to be replaced.

Microwave producing a burning smell

The magnetron uses high voltage, high current DC power to generate the microwave frequency that cooks the food. If the magnetron burns out, it can produce a burning smell and the microwave won’t heat. The magnetron is not repairable—if the magnetron is burned out, you must replace it. (Warning: The microwave oven can store a lethal amount of electricity in its high voltage capacitor, even after the microwave oven has been unplugged. Due to the high running voltage and the potential for electric shock, it is extremely dangerous to replace the electronic components in a microwave. Only a licensed technician should replace the magnetron.)
